RAM Mounts Form-Fit Halteschale (mit Schnappverschluss) für Zebra ET40 & ET45 10 Zoll Tablets (mit Rugged Boot) - 5.5mm DC Stromversorgung & Dual USB-A Stromanbindung - AMPS 4-Loch Aufnahme - VESA 75x75 - Schrauben-Set
This RAM Mounts Form-Fit (latch) holder is suitable for Zebra ET4x 10“ series with Rugged Boot.
The holder is powered by a 5.5mm DC connection and charges the device in the dock while peripheral support is provided by the built-in dual USB Type-A cable.
To insert the device, place the bottom of the device in the cradle and press it into the cradle until it clicks into position.
The cut-outs on the buttons and ports allow you to continue using them without any problems.
The cradle also allows the tablet's scanning function to continue to be used because of the cutout at the back.
Tablet accessories such as PowerPack batteries can also be stored inside.
The back of the device holder is prepared to support a VESA 75x75 mm or round ball base (not included).
Product features RAM Mounts RAM-HOL-ZE21PDNLLU:
- Compatible with PowerPack batterie
- Easy insertion and removal
- Additional mounting plate for attaching additional devices or accessories
- Only for Zebra Tablets within Rugged Frame (Boot)
- With Latch
- Input Connector: 5.5mm DC-Connector
- Output Connector: 2x USB-A 2.0 (Peripheral output - 900mAh per Port)
- Transfer Speed: 12Mbps
- Input Cable Length: ca. 100 cm
- Output Cable Length: ca. 24 cm
- Certifications: RoHS, WEEE, CE & UKCA
Additional information:
To support the tablet without the Rugged Boot, see RAP-INSERT-ZE21LU.
This dock is not compatible with IntelliSkin.
For IntelliSkin with GDS Tech, see RAM-GDS-DOCKNLL-ZE21PD2U.
Devices shown are not included in the delivery.
Only the RAM-HOL-ZE21PDNLLU holder is supplied.
| Hole Pattern: | AMPS 4-Loch |
|---|---|
| Manufacturer: | Zebra |
| Mounting: | Schrauben |
| Zebra Rugged PC: | ET4x 10 Zoll |
| EAN: | 793442017131 |
Compatible
RAM-101U-2461
(410338)
RAM-101U-B-2461
(580044)
RAM-D-254-C-235U
(582212)
RAM-D-2461U-C-247-4
(585940)
Compatible Base
RAM-2461U
(410687)
RAM-202U
(410074)
RAM-D-2461U
(410584)
RAM-D-202U
(410307)
Compatible Arms
RAM-201U-B
(410903)
RAM-201U
(410747)
RAM-201U-D
(410648)
RAM-D-201U-C
(410582)
RAM-D-201U
(410306)
RAM-D-201U-E
(410432)
Options
RAM-GDS-CHARGE-V9U
(583560)
RAM-GDS-CHARGE-V10-1U
(586513)
RAM-GDS-HS2-ZE21U
(410632)
RAM-GDS-ROTO2-ZE21U
(410625)
RAM-GDS-HS1M-ZE21U
(410627)
RAM-DOCK-HEATER1-DU
(411071)
RAM-VENT1-RND-50U
(586401)
RAM-VENT1-RCT-50U
(586384)
